Table of Contents
I. Pre-Installation .......................................7
II. Knockdown Boiler Assembly ................9
III. Water Piping and Trim .........................12
IV. Venting .................................................18
V. Electrical and Sequence of Operation ..20
Figure 1: RSA Packaged Boiler (RSA85 / RSA135)
VI. Oil Piping .............................................
28
VII. System Start-Up ................................... 30
VIII. Service and Cleaning............................38
IX. Repair Parts ..........................................
40
X. Appendix
Low Water Cut Off ...............................50
Boiler Model Number Dim. ‘A’
Minimum Recommended Chimney Sizes
Water
Capacity
(gallons)
Approx.
Shipping
Weight (lb.)
In. x In. x Ft. (ht.) In. (dia.) x Ft. (ht.)
RSA85
34¾
8 x 8 x 20
6 x 15
9.1
300
RSA110 8.5
RSA125
41¼
13.9 340
RSA135 7 x 15 13.0 355
