38
ASSEMBLING THE PELLET CHAMBER
ATTACHING THE GRILLING CHAMBER
Pace the grilling chamber onto the
base cabinet. Make sure that the cham-
ber is located between the left and
right-side panels.
Screw the grilling chamber onto the
side panels.
9
10
Pace the funnel onto the pellet chamber. Make
sure that the lid opens to the front side (operating
element).
7
Open the lid and insert the pre-assembled screws
into the cap nuts through the holes in the funnel
from the outside. Tighten from the inside.
8
