39
ATTACHING THE PELLET CHAMBER
Connect the RTD connector from the inside of
the grilling chamber to the counter plug on the
outside. Warning: Any excess wire of the RTD plug
should be located outside of the chamber.
11
Slide the combustion chamber into the grilling
chamber using the provided opening.
Open the funnel lid and screw the pellet cham-
ber onto the grilling chamber from the inside.
12
13
11
12
13
To Next Page
