2 | Product Description
4 / 24 0870169526_KB_KC0010-0016E_A0004_IM_en
2 Product Description
OFP
NP
MTB OS EF IN OUT GB
ODP OSG
IN Suction connection GB Gas ballast valve
OUT Discharge connection MTB Motor terminal box
OFP Oil fill plug EF Exhaust filter
OSG Oil sight glass NP Nameplate
ODP Oil drain plug OS Oil separator
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum
pump’.
