BUSCH SV 1010 C - Page 14

7 | Maintenance
14 / 24 0870569132_SV_SD_DC1010-1040C_-0005_IM_en
4x
1
2
3
4
H
Check vane height
5 mm hex key
SV/SD 1010-1016 C:
SV/SD 1025-1040 C and
DC 0025-0040 C:
SV/SD 1010-1016 C:
SV/SD 1025-1040 C and
DC 0025-0040 C:
H 33 mm
H 27 mm
H 27 mm
H 33 mm
≤
≤
>
>
Zirkon
EK-60
SV 1025-1040 C
H 33 mm
SV 1025-1040 C
H 33 mm
≤
>
Maintenance 3000h / 1year
≤
1
3
2
4x
4
Busch genuine spare parts
7x vane (VA)*
5 mm hex key
* The vane type acc. to the specification (only for the SV 1025/1040 C)
