BUSCH SV 1010 C - Suction Connection; Discharge Connection; Electrical Connection

Installation | 5
0870569132_SV_SD_DC1010-1040C_-0005_IM_en 9 / 24
5.2.1 Suction Connection
NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
• Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– G1/2 for SV/SD 1010-1016 C
– G3/4 for SV/SD 1025-1040 C and DC 0025-0040 C
Depending on the specific order, other connection dimensions may apply.
5.2.2 Discharge Connection
Connection size(s):
– G1/2 for SD 1010-1016 C
– G3/4 for SD 1025-1040 C and DC 0025-0040 C
– No dimension for SV 1010-1040 C ► discharge valve (DV)
Depending on the specific order, other connection dimensions may apply.
• Make sure that the discharged gas will flow without obstruction. Do not shut off or
throttle the discharge line.
5.3 Electrical Connection
DANGER
Live wires.
Risk of electrical shock.
• Electrical installation work must only be executed by qualified personnel.
• Make sure that the power supply for the motor is compatible with the data on the
nameplate of the motor.
• The electrical installation must comply with applicable national and international
standards.
• Provide a lockable disconnect switch on the power line so that the machine is com-
pletely secured during maintenance tasks.
• Provide an overload protection according to EN 60204-1 for the motor.
• Make sure that the motor of the machine will not be affected by electric or electro-
magnetic disturbance from the mains; if necessary seek advice from Busch.
• Connect the protective earth conductor.
• Electrically connect the motor.
NOTICE
Incorrect connection.
Risk of damage to the motor!
• The wiring diagrams given below are typical. Check the inside of the terminal box for
motor connection instructions/diagrams.
