2 | Product Description
4 / 24 0870569132_SV_SD_DC1010-1040C_-0005_IM_en
2 Product Description
SD series (pressure)
SV series (vacuum) DC series (vacuum/pressure)
MTB NP EB IN OUT VA
PRV
IDFIIF
DV/OUT
RFDA
VRVINOUTVRVIN
only on SVoptional on SV
only on SD/DC
standard on DC standard on DC
standard on SD
PRV
IN Suction connection MTB Motor terminal box
OUT Discharge connection DA Directional arrow
VA Vane NP Nameplate
IIF Internal inlet filter VRV Vacuum regulating valve
IDF Internal discharge filter PRV Pressure regulating valve
EB Eye bolt DV Discharge valve
RF Radial fan
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum
pump’ or ‘compressor’.
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
