4 TECHNICAL DATA AND LIMITATIONS OF USE
Power supply voltage: Single-phase, 230 V, 50/60 Hz. See data plate.
Three-phase, 230 - 400 V, 50/60 Hz.
Motor Protection: “IP 55”
Insulation class: Class “F”
MAXIMUM ENVIRONMENTAL TEMP.: +40ºC
MAXIMUM PUMPED LIQUID TEMP.: +40ºC
5 TRANSPORT
Do not subject the products to unnecessary bumps and knocks.
When lifting and transporting the unit, use machines and tools that have been designed for this purpose, using the
pallet supplied as standard (if present).
6 STORAGE
All the pumps should be stored in a sheltered, dry, dust-free place, with regulated air-moisture levels when possible.
The pumps are supplied in their original packaging, where they must remain until assembly. If not, keep the suction
and discharge ports closed.
7 INSTALLATION
7.1 General
The pump should be installed as close as possible to the level of water, leaving a minimum of two metres
to the swimming pool edge in accordance with IEC publication No. 364 in a horizontal position, to obtain
minimum run length in suction and a reduction of load losses.
Sufficient space should be allowed for removing to pre-filter basket for cleaning and re-fitting.
The pump should be installed on a solid, very smooth surface. It is necessary to perfectly fit the pump through the
two holes provided for this purpose in the support base by means of two screws or other similar methods to prevent
any possible noise or vibration that could adversely affect the pump operation.
The pump should not be installed at a geometric height of more than 3.5 metres above the water level.
In order to obtain optimum pump self-priming, it should be installed at a maximum of 2.5 metres above the water
level.
The pump should be protected from any possible flooding and correct ventilation should be ensured, but without
risking the effects of freezing. In the case of outside installation, the pump should be protected from rain and a
power supply cable in accordance with EEC standards, type H07-Requirement Number-F (in accordance with VDE
0250) should be installed. The pump is normally supplied without an electric power cable. In this case the pump
test cables can be seen to be cut at the outlet of the motor junction box. These cables must be replaced by a
suitable electric hose in accordance with the legislation in force in each country.
