15 DIMENSIONS / ABMESSUNGEN / DIMENSIONS / AFMETINGEN /
DIMENSIONES / DIMENSIONI / DIMENSÕES
In mm
Model HP A B C C* E F F* G H I D
33 555 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
50 555 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
75 555 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
100 555 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
150 585 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
200 585 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
300 635 269 321 327 281 243 249 350 240 168 Ø 50/63 D 50/63
