Lightning Series Fiber Laser User Manual
6
Power stability
（
25℃
）
＜
±1.5% (2h)
Max modulation
frequency
5kHz
Weight
~14.5kg
~17kg
~33kg
~67kg
Dimension
H*W*D, mm
80*402*296
80*402*346
80*482*521
93*482*861
Voltage
Single phase ,220±20V,AC,PE,50/60Hz
3phases ,380±20V,AC,PE,50/60Hz
Power
consumption
1.5kW
3.0kW
4.5kW
6.0kW
9.0kW
18.0kW
Control interface
RS-232/AD
Minimum water
cooling capacity
≥1kW
≥2.5kW
≥3.5kW
≥4.5kW
≥7.0KW
≥13.0kW
Temperature
settings
25℃ (Laser Module), 30℃ (QBH)
Cooling water flux
>8L/min
>10L/min
>15L/min
>18L/min
>25L/min
>55L/min
Cooling water
pressure
≤
0.5MPa
QBH cooling
water flux
1.5~2.0L/min
Cooling tubes size
O.D. φ12mm
I.D. φ19mm
I.D. φ25mm
3.4. Unpacking and Inspection
The laser is carefully packaged before shipping out from the factory for safe transportation,
but in case of any unpredictable situation in transportation process, you need check the packaging
box for the crack, soaking, etc., when you receive the laser. If any damage is found, please contact
BWT representative in time.
If no damage on package, you can unpack the laser. After unpacking, please carefully check
whether the contents in the box are consistent with the packing list.
When removing the packing foam, do not pull hard the output fiber. Remove the protective
cap on the end of the output fiber, and check the end surface. There should be no stains or cracks
on it. If there is any damage, please contact BWT representative in time. Please note, do not
contaminate the output end surface when you check it.
When taking out the laser from the package box, avoid collision and strong vibration to the
