3.8. Power Requirements and Wiring Definitions
Table 8 Power Requirements and Wiring Definitions
Laser model
Power
consumption
Maximum
operating current
Input power
Definition of power
supply wiring
BFL-CW500
1.5 kW
8A
220V/50Hz-60Hz
1-L- live wire, 2-N-
Neutral wire, 3-PE-
Ground wire.
BFL-CW1000
3.0 kW
18A
BFL-CW1500
4.5 kW
21A
BFL-CW2000
6.0 kW
36A
BFL-CW3000
9.0 kW
16A
AC 380V/50-60Hz
L1-Live wire, L2-Live
wire, L3-Live wire,
PE-ground wire.
BFL-CW6000
18.0 kW
30A
If the local voltage fluctuation exceeds ±5%, which means out of the limits required by the laser, please use a
regulated power supply with appropriate power.
