laser and the laser output head. When taking out the coiled output fiber, do not bend, twist or pull
the output fiber.
The laser should be placed on a flat and firm table in a room with good ventilation.
Table 3 Laser packing list example
No.
Item
Qty.
Note
1
Laser system
1
2
Power cable
1
3
Control interface cable
1
DB25
4
Communication interface cable
1
R232
5
DB9 extension cable
1
6
8-pin wiring plug
1
For connection of switch interlock interface
7
USB flash drive
1
Contains PC software and electronic manuals, etc.
8
Quick guidance
1
9
Gas tube
1
Outer diameter φ6mm
10
Throat hoop
4
For BFL-CW3000 and BFL-CW6000 only
11
O-ring 1
1
Inner diameter φ11.2 × wire diameter φ1.8
12
O-ring 2
1
Outer diameter φ16×wire diameter φ1.5
13
cotton swab
1
Can be used for surface cleaning of QBH quartz block
14
dust-free cloth
10
Can be used for surface cleaning of QBH quartz block
15
Rubber dust cover
1
Note: the packing list may be different in terms of configuration. Please refer the packing list delivered
with laser.
3.5. Panel Description
