5.1.3 Configure Static IP Address WAN Connection for Internet in Route Mode
1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then
there are some parameters for us to configure as follows:
【WAN Connection name】Select ‘Add WAN Connection’
【Mode】Select ‘ Route ’
【 Connection Mode 】 Select ‘Ipv4’; If there is Ipv6 in the network, we can select
‘ Ipv4/Ipv6 ’.
【Internet way】Select ‘Static’
【NAT】Check ‘ NAT ’ feature；NAT is mainly used for address translation function of
local network and external network. The default is checked enable status. If you
do not check this option, maybe you can’t surf the internet.
【Enable Vlan】We can set this option according to your network plan. If there is vlan in
the network for internet, we have to check ‘Enable VLAN’ option. If not,
we needn’t check this option, which will be VLAN transparent mode.
【Vlan ID】Configure this option according to our network plan.
【MTU】The default is 1500；we have to change to lower MTU, such as 1400, if we can
ping the DNS but not access the website via WEB broswer.
【IP Address】Set static IP address
【Subnet Mask】Set the mask of static IP address
【Default Gateway】Set the default gateway of static IP address
【Primary DNS / Secondary DNS】Set static primary DNS address and secondary DNS
address
【Service Mode】Select Internet；Normally, select ‘Internet’ in the route mode.
【LAN DHCP Disable】Don’t check this option；Normally, Terminal , connected to the
HGU ONU, will get an IP address from the ONU’s IP pool.
Therefore, we needn’t check this option to get the IP address.
【Bind port】 Bundel the physical ports (Lan port 1-4 and wireless) with Static IP WAN
connection.
Note: By default, all LAN ports and WIFI data are not bound by this WAN connection (a
LAN and WIFI SSID can only be bound to a WAN conection at the same time).
