SPECIFICATIONS – CONTINUED
PARAMETER LOW-VOLTAGE
SERIES 90
HIGH VOLTAGE
SERIES 90HV
TEST SPEED
Continuity: 500 points/sec
Component: 50 points/sec
High Current: 20 points/sec
Isolation: 20 points/second*
(* plus dwell & ramp-up time)
BODY
CONDUCTANCE
Less than 10 µA
LAMP/RELAY
DRIVERS
Scanner boards can be assigned to drive lamps and relays.
Up to 100 mA @ 5 VDC per
point
Up to 1 A @ 5 VDC per point
INPUT POWER
Series 90/90HV System Controller: 100 to 252 V~, 5 A, 50/60 Hz.
All Series 90 Expansion Cabinets: 100 to 252 V~, 1 A, 50/60 Hz.
