SPECIFICATIONS – CONTINUED
PARAMETER LOW-VOLTAGE
SERIES 90
HIGH VOLTAGE
SERIES 90HV
DIMENSIONS/
WEIGHT
(Height x Width x Depth)
Series 90/90HV System Controller:
6.0 x 23.5 x 15.0 inches (15.2 x 59.7 x 38.1 cm)
26 Ibs (11.8 kg)
Series 90-S9 Expansion:
6.0 x 23.5 x 15.0 inches
(15.2 x 59.7 x 38.1 cm)
21 lbs (9.5 kg) plus
1 lb (0.5kg) per 128 points
Series 90-S32 Expansion:
15.0 x 23.5 x 15.0 inches
(38.1 x 59.7 x 38.1 cm)
31 lbs. (14.1 kg) plus
1 lb (0.5kg) per 128 points
Series 90L4:
12.75 x 7.0 x 12.25 inches
(32.4 x 17.8 x 31.1 cm)
18 lbs. (8.2 kg) plus
1 lb. (0.5kg) per 128 points
Series 90L8:
12.75 x 9.75 x 12.25 inches
(32.4 x 24.8 x 31.1 cm)
18 lbs. (8.2 kg) plus
1 lb. (0.5kg) per 128 points
Series 90HV-S23 Expansion:
14.5 x 24.1 x 12.0 inches
(36.8 x 61.2 x 30.5 cm)
32 lbs (14.6 kg) plus
1.5 lbs (0.68kg) per 64 points
Series 90H8
12.75 x 9.75 x 12.25 inches
(32.4 x 24.8 x 31.1 cm)
18 lbs. (8.2 kg) plus
1.5 lb. (0.68g) per 64 points
Cablescan makes product improvements as required and therefore all specifications and system
configurations are subject to change without notice.
