CADDX xGenConnect - Power and Environmental Specifications

xGenConnect Installation and Programming Guide 3
Product
Description
EN grade
NXG-003
Housing /w tamper sw – Metal EN Grade 2
2
NX-002
Small metal enclosure for NXG-4, no cam lock, no tamper
2
NX-003
Standard metal enclosure for NXG-8/8E, with cam lock, no
tamper
2
NX-003-CB
Large metal enclosure for NXG-8/8E, with cam lock, tamper,
including stand-offs
2
NX-005-C
Housing tamper switch
2
NXG-003-DIN
DIN-rail mounting kit
2/3
NXG-868
Wireless expander 868 MHz Gen 2
2
NXG-433
Wireless expander 433 MHz
2
NXG-7002(-SIM)
4G/Wi-Fi communication expander (-SIM includes SIM card)
2
NXG-7102(-SIM)
4G communication expander (-SIM includes SIM card)
2
Mains Power Specifications
Mains input voltage
230 VAC +10%, −15%, 50/60 Hz ±10%
Current consumption at 230 VAC
240 mA max.
Transformer output:
NXG-4, NXG-8(E)
16.3 VAC 40 VA
NXG-9
20 VAC 40 VA
Installation Instructions for Service Persons
An appropriate disconnect device, to control the mains power to this device, is to
be provided as part of building installation according to the local wiring rules.
Power Supply Specifications
Power supply type
EN 50131-6 Type A for indoor use inside the
supervised premises
Power supply voltage
13.8 VDC ± 0.4 V
Power supply current
2 A max. at 13.8 VDC ± 0.4 V
Main board consumption:
NXG-4
140 mA at 13.8 VDC ± 0.4 V
NXG-8(E)
125 mA at 13.8 VDC ± 0.4 V
NXG-9
150 mA at 13.8 VDC ± 0.4 V
Maximum system current available:
2000 mA at 13.8 VDC ± 0.4 V
Auxiliary power output (AUX. POWER):
13.8 VDC ± 0.4 V, 600 mA max.
Auxiliary power output (bus):
13.8 VDC ± 0.4 V, 600 mA max.
Battery power output (BAT):
NXG-4
13.8 VDC ± 0.2 V, 350 mA max.
NXG-8(E)
13.8 VDC ± 0.2 V, 350 mA max.
