CADDX xGenConnect - Fuses; Maintenance; System Monitoring

8 xGenConnect Installation and Programming Guide
Product
Main description
Dimensions (HxWxD)
Weight (g)
NXG-003(-G3)
Metal Enclosure
475 x 395 x 130 mm
7150 g
NXG-1820-EUR
Touchscreen keypad
18 x 82 x 125 mm
150 g
NXG-183x-EUR
LCD keypad
133 x 130 x 25 mm
300 g
NXG-208
8 zone expander
135 x 80 x 55 mm
150 g
NXG-208N
xGenConnect 8 zone
expander board
153 x 57 mm
60 g
NXG-216N
xGenConnect 16 zone
expander board
153 x 57 mm
60 g
NXG-220
20 zone expander
135 x 80 x 64 mm
180 g
NXG-504
4 relay output expander
135 x 80 x 55 mm
150 g
NXG-508N
xGenConnect 8 relay
expander board
153 x 57 mm
70 g
NXG-510
10 relay output expander
135 x 80 x 64 mm
180 g
Fuses
Battery
4 A, resettable
12 V aux (combined for J2 BELL+, J2 AUX+, J7 AUX+)
NXG-8(E)
1.1 A, resettable
NXG-9
2 A, resettable
System LAN (combined for J2 POS, J3 POS)
NXG-8(E)
1.1 A, resettable
NXG-9
2 A, resettable
Mains, mains fuse
Note: Mains fuse is a part of the mains terminal block.
500 mA, fast 20x5
Maintenance
No regular maintenance needed. System will report servicing when necessary.
System Monitoring
The system provides monitoring for the following items.
Monitoring function
Message
Cause
AC Mains
Mains fail
Loss of external power supply
Battery
Battery low
Battery low voltage
Battery test fail
Exhausted battery
Battery charger fail
Fuse/power output fail
Output overload
