CADDX xGenConnect - Output Current Rating; Auxiliary Current and Battery Capacity

6 xGenConnect Installation and Programming Guide
Product
Main description
Current Consumption
(non-alarm)
Current
Consumption (alarm)
NXG-1820
Touchscreen keypad
100 mA typical, 40 mA in
idle mode
175 mA max with
sounder and screen on
max brightness
NXG-1830-EUR,
NXG-1831-EUR
LCD keypad
90 mA typical, 35 mA
minimum
160 mA max.
NXG-1832-EUR,
NXG-1833-EUR
LCD keypad with
integrated Mifare card
reader
130 mA typical, 40 mA
minimum
200 mA max.
NXG-208-G3
8 zone expander
25 mA
25 mA
NXG-208N
xGenConnect 8 zone
expander board
30 mA
30 mA
NXG-216N
xGenConnect 16 zone
expander board
30 mA
30 mA
NXG-220-G3
20 zone expander
30 mA
30 mA
NXG-504
4 relay output expander
20 mA idle
70 mA 4 relays on
20 mA idle
70 mA 4 relays on
NXG-508N
xGenConnect 8 relay
expander board
20 mA idle
130 mA 8 relays on
20 mA idle
130 mA 8 relays on
NXG-510
10 relay output expander
20 mA idle
160 mA 10 relays on
20 mA idle
160 mA 10 relays on
NXG-7002
4G Cellular and Wi-Fi
Router Module
118 mA minimum,
138 mA average
200 mA
Output Current Rating
Output
35 VA
Transformer
40 VA
Transformer
55 VA
Transformer
Combined J2 BELL+, J2 AUX+ (Smoke),
and J7 AUX+ (Outputs)
500 mA max at
13.8 VDC
600 mA max at
13.8 VDC
600 mA max at
13.8 VDC
Combined J2 POS (XR Bus), and J3 POS
(NX Bus)
500 mA max at
13.8 VDC
600 mA max at
13.8 VDC
600 mA max at
13.8 VDC
Auxiliary Current and Battery Capacity
xGenConnect (EMEA)
Discharge
Time
Charge
Time
7.2 Ah
Battery
12 Ah
Battery
18 Ah Battery
Reference
NXG-4
12 h
72 h
460 mA
N/A
N/A
EN 50131 Grade 1 and 2
24 h
48 h
160 mA
N/A
N/A
INCERT Grade 2
NXG-8(E)
12 h
72 h
475 mA
875 mA
1200 mA
EN 50131 Grade 1 and 2
