CADDX xGenConnect - Physical Dimensions and Installation Details

xGenConnect Installation and Programming Guide 7
Discharge
Time
Charge
Time
7.2 Ah
Battery
12 Ah
Battery
18 Ah Battery
Reference
24 h
48 h
175 mA
375 mA
625 mA
INCERT Grade 2
NXG-9
12 h
72 h
450 mA
850 mA
N/A
EN 50131 Grade 1 and 2
24 h
48 h
150 mA
350 mA
N/A
INCERT Grade 2
Note: Main board quiescent current is included in the table above.
Example for NXG-8 EN Grade 2
When using battery backup as specified for EN Grade 2 using a 7.2 Ah battery,
the maximum available auxiliary current is 475 mA.
Environmental
Operating temperature
−10 to +55°C
Humidity
95% non-condensing
IP protection grade
IP30
NXG-4, NXG-8(E) metal enclosure
EN 50131 Grade 2, Class II
NXG-9 polycarbonate enclosure
EN 50131 Grade 2, Class II
Alarm transmission class EN50136-2/EN 50131-10:
Onboard IP
SP4 & DP3
Cellular
SP4 & DP3
NXG-1820 ACE classification
Type A
NXG-183x ACE classification
Type A
Physical Dimensions and Weight
Product
Main description
Dimensions (HxWxD)
Weight (g)
NXG-4(-RF)
xGenConnect /w metal
enclosure
214 x 232 x 94 mm (enclosure
only)
359 x 232 x 94 mm (with
antennas)
1435 g
NXG-8(E)
NXG-8(E) /w standard metal
enclosure
292 x 291 x 91 mm
2075 g
NXG-8(E)-CB
NXG-8(E) /w large metal
enclosure
394 x 256 x 118 mm
7150 g
NXG-9-RF
NXG-9 /w standard poly
housing
220 x 253 x 112 mm
1800 g
NXG-9(-RF)-LB
NXG-9 /w large poly housing
394 x 256 x 118 mm
2800 g
NXG-8-BO
NXG-8, board only
273 x 89 x 25 mm
210 g
NXG-4(-RF)-BO
NXG-4, board only
192 x 89 x 25 mm
155 g
NXG-9(-RF)-BO
NXG-9, board only
210 g
NXG-001
Plastic Enclosure
371 x 371 x 118 mm
1830 g
