Cafection Encore 29 - Bean Hopper Installation

EN1805CMINSA Rev. 5 2021-10
www.cafection.com 800-561-6162
14
SERVICE & INSTALLATION MANUAL - Encore 29
3.7 Bean Hopper Installation
The hopper is already installed in the brewer when shipped. To remove it for cleaning or servicing,
follow the steps below.
1. Open the brewer’s door.
2. Pull down the bean hopper retaining pin.
3. At the same time, pull the bean hopper forward.
4. To reinstall, slide the bean hopper back in place. The retaining pin does not need to be pulled
down.
Reference Drawings
Bean hopperRetaining pin
