Guidance and Manufacturer’s Declaration—Electromagnetic Immunity
The Eclipse 5 is intended for use in the electromagnetic environment specified below. The customer or the user of the Eclipse 5
should assure that it is used in such an environment.
Immunity test
Compliance level
Electromagnetic environment – guidance
Electrostatic discharge (ESD) IED
61000-4-2
±8 kV contact
±15 kV air
Floors should be wood, concrete or ceramic tile. If floors are
covered with synthetic material, the relative humidity should
be at least 30 %.
Electrical fast transient/burst
IEC 61000-4-4
±2 kV
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5
±1 kV
±2 kV
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short interruptions
and voltage variations on power
supply input lines IEC 61000-4-11
100V-240V
Mains power quality should be that of a typical commercial or
hospital environment. If the user of the Eclipse 5 requires
continued operation during power mains interruptions, it is
recommended that the Eclipse 5 is powered from an
uninterruptible power supply
(UPS).
Power frequency magnetic field
IEC 61000-4-8
30A/m
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical commercial or
hospital environment.
Conducted RF
IEC 61000-4-8
10 Vrms
150 kHz to 80 MHz
The Eclipse 5 complies with all applicable electromagnetic
compatibility requirements (EMC) according to IEC 60601-1-
2:2014, for residential, commercial and light industry
environments. Portable and mobile RF communications
equipment should be used no closer to any part of the
machine, including cables, than the recommended 10cm
separation distance. The Eclipse 5 has been designed to meet
EMC standards. However, should you suspect that the machine
performance (e.g. pressure or flow) is affected by other
equipment, move the machine away from the possible cause of
the interference.
Radiated RF
IEC 61000-4-6
9 V/m to 85 V/m
At frequencies, up to 5.785GHz
The Eclipse 5 complies with Part 15 of the FCC rules and
industry Canada license-exempt RSS standards. Operation is
subject to the following two conditions: this machine may not
cause harmful interference, and this machine must accept any
interference revived, including interference that may cause
undesired operation.
FCC ID: WAP2001
