Oxygen Concentrator Technical Service Manual | PN 20631679 Rev G
7
ECLIPSE 5 OXYGEN SYSTEM SPECIFICATIONS
Oxygen Concentrator
Dimensions (H x W X D)
19.3 x 12.3 x 7.1 inches
(49.0cm x 31.2cm x 18.0cm)
Weight
Eclipse 5
Power Cartridge
15.0 pounds
3.4 pounds
Flow Settings
Continuous Flow (measured in Liters Per Minute LPM) Pulse
Dose (measured in mL)
0.5 to 3.0 LPM (0.5 liter increments)
Settings 1.0-6.0: 16mL, 24mL, 32mL, 40mL, 48mL, 56mL, 64mL, 72mL, 80mL, 88mL, 96mL
Settings 7-9: 128mL, 160mL, 192mL
Continuous Flow Accuracy
+/- 10% or 200ml/min, whichever is greater
Oxygen Concentration
87–95.5% for all flow settings
Maximum System Pressure
14 psig (96.5 kPa)
Oxygen Output Pressure
5.0 psig (34.5 kPa) nominal
Oxygen Concentration
Status Indicator
Green Light = Normal Operation
Yellow Light = Warning or Caution, less than 85% ± 3%
Red Light Flashing = Abnormal Operation, less than 70% ± 5% (Note: only for 3-LED models)
Nominal Sound Level
3.0 LPM Continuous Flow
3.0 Pulse Dose Mode
48 dB(A)
40 dB(A)
Less than 57 dB while alarming
Operating Environment
Temperature
Humidity
50º F to 104º F (+10° to 40°C)
10% to 95%, Non-condensing, 82.4°F (28°C) Maximum Dew point
Storage Environment Temperature
Humidity
-4º F to 140º F (-20° to 60°C)
Up to 95% Non-condensing
Altitude
0 – 13,123 feet (0 - 4,000 meters)
Nominal Power
0.5 LPM Continuous flow 3 LPM
Continuous Flow
1.0 Pulse Dose Setting
6.0 Pulse Dose Setting Battery
Charging
48 Watts
145 Watts
45 Watts
95 Watts
50 Watts
Nominal Power Cartridge operating time* Continuous
Flow
2.0 LPM
3.0 LPM
Pulse Dose (@ 12 BPM)
Setting 2.0
Setting 6.0
2.0 hours
1.3 hours
5.2 hours
3.5 hours
* Note: Times will decrease with higher bolus size, breath rate, ambient temperature, power
cartridge age and use over time.
Outlet Pressure
Nominal: 7.0 psig
Maximum: 14.0 psig
Continuous Flow Indication
Expressed in liters per minute (LPM)
Audible Alarm Indicators
• Loss of Power/Hot Power Cartridge
• Low Power Cartridge/Warm Power Cartridge
• Low Oxygen Output
• O
2
Flow Outside Normal Limits
• Unit Malfunction
• Low 9V battery (Note: only for 3-LED model)
