CAIRE Eclipse 5 with autoSAT - Device Symbols and Compliance; Device Symbols Explained; Regulatory Compliance & Aircraft Use

Oxygen Concentrator Technical Service Manual | PN 20631679 Rev G
5
Drip Proof Equipment -
IP22: The Eclipse 5 and the
AC power supply provide
protection against the harmful
effects of ingress of liquids
(IP22 per IEC 60529)
IEC 60601-1-8
Low Priority Technical
Alarm
FCC NOTICE:
This device may contain
CYBLE-022001-00, including the
antenna 2450AT18B100 from Johnson
Technology, complies with par 15 of
the FCC rules. The device meets the
requirements for modular transmitter
approval as detailed in FCC public
Notice DA00-1407. Transmitter
operation is subject to the following two
conditions (1) This device may not cause
harmful interference, and (2) This device
must accept any interference received,
including interference that may cause
undesired operation.
This product may be covered by one
or more patents, US and international.
Please visit our website below for the
listing of applicable patents. Pat.: patents.
gtls.io.
Aircraft Use:
CAIRE confirms that this machine meets
the Federal Aviation Administration
(FAA) requirements (RTCA/DO-160,
section 21, category M) for all phases of
air travel.
Wireless Technology
Technology used
Bluetooth
Connection types
SSP, iAP2, GATT
Frequency
2402 to 2480 MHz
Max RF power output
+4 dBm
Operating range
10m (Class 2)
It is recommended that the machine is at a
minimum distance of 0.43” (1.1 cm) from the
body during operation. Not applicable to masks,
air tub- ing, or accessories.
Internal Symbols
External Power Indicator
Power Cartridge (battery)
Status Gauge
Power Cartridge Symbol
A
Amperes
0
2
Oxygen Output
Recycle Symbol
FAA Approved Symbol:
The U.S. Federal Aviation
Administration (FAA) has
approved this device for
use on-board commercial
aircraft.
Flow Setting Indicator
Pulse Mode Operation
Device operating normally;
power button
Increase Flow Setting
Decrease Flow Setting
ISO 7000; Graphical symbols for use on
equipment—Index and synopsis
Storage temperature limitation
range is -4°F to 140°F (-20°C
to 60°C). Reg. # 0632
Portable humidity range is 15 to 95%.
Base humidity range is 30 to 75%.
Reg. # 2620
Atmospheric pressure limitation. Reg.
# 2621
Operator’s manual; operating instruc-
tions. Reg. # 1641
Name and address of
manufacturer. Reg. # 3082
Date of manufacturer. Reg. #
2497
Catalog Number. Reg. #
2493
Serial Number. Reg. # 2498
This way up. Reg. # 0623
Fragile, handle with care.
Reg. # 0621
Keep away from rain, keep dry. Reg.
# 0626
Stacking limit by number. Reg. # 2403
ISO 7010: Graphical symbols—Safety colors
and safety signs—Registered safety signs
The instruction manual must
be read. Reg. # M002
Keep away from open
flame, fire, sparks. Open
ignition source and smoking
prohibited. Reg. # P003
Do not smoke near unit or
while operating unit. Reg. #
P002
Council Directive 93/42/EEC; concerning
medical devices
Authorized representative in
the European Community
This device complies with
the requirements of Directive
93/42/EEC concerning
medical devices. It bears the
CE marking as shown.
IEC 60417
Class II Equipment, Double
Insulated Reg. # 5172
Alternating Current Reg. #
5032
Direct Current Reg. # 5031
Type BF applied part (degree
of protection against electric
shock). Reg. # 5333
CSA Certification
Certified for both the U.S.
and Canadian markets, to the
applicable U.S. and Canadian
standards.
FCC Notice
21 CFR 801.15: Code of Federal Regulations
Title 21
Federal law restricts this
device to sale by or on the
order of a physician.
Council Directive 2012/19/EU: waste electrical
and electronic equipment (WEEE)
WEEE
IEC 60601-1: Medical electrical equipment
Part 1 General requirements for basic safety
and essential performance
