Cal Spas F 1239 - Electrical Installation for 8.5 Kw Heater

2012 Portable Spa
LTR20121001, Rev. A
Preparing for Your New Portable Spa
www. c a l s p a s. c o m
10
SERVICE 2
INPUT POWER 32 AMPS
2 WIRES
HOT, NEUTRAL
AWG # 10
SERVICE
INPUT POWER 32 AMPS
3 WIRES
HOT, NEUTRAL, GROUND
AWG # 10
3.0 KW OUT
5.5 KW IN
Electrical Installation for 8.5 kW Heater
This applies to Ultimate Fitness spas with the 8.5 kW heater only.
Two electrical services are required to heat the swim side of the Fitness Spa.
