California Instruments MX Series - 8 Top Assembly Replaceable Parts

User Manual - Rev AV AMETEK Programmable Power
MX Series 192
8. Top Assembly Replaceable Parts
Note that different generation MX units may use different sub assemblies. Check the serial tag on the
back of the MX to determine the applicable top assembly number to determine the correct sub assembly
or part required. For amplifiers, refer to the amplifier serial tag for the relevant amplifier top assembly part
number.
Ref. CI P/N Description Vendor
Qty
Location
Top Assembly 7003-427 / 7003-422
A2
7003
-
421
-
1
Front Panel Assy. Prog. Osc.
AMETEK PP
1
7003-718-2 CPU board assy. All 3 phase
MX.
AMETEK PP 1
7003-718-4 CPU board assy. MX30-1,
MX45-1 only.
AMETEK PP 1
7000
-
723
-
4
Keyboard/Display assy.
AMETEK PP
1
Top Assembly 7003-400
A2 7003-401-1 Front Panel Assy. Prog. Osc. AMETEK PP 1
5100
-
707
-
2
CPU / Phase A board assy.
AMETEK PP
1
7000-722-2 Phase B/C board assy. AMETEK PP 1
7000-723-1 Keyboard/Display assy. AMETEK PP 1
Top Assembly 7003-427
A1 7003-721-1 PC Assy. RS232 / GPIB / USB AMETEK PP 1
A1 7003-721-2 PC Assy. RS232 / GPIB / USB /
LAN
AMETEK PP 1
A6 7003-722-1 PC Assy., Low Volt PSU AMETEK PP 1
7003
-
723
-
1
Ripple Filter
AMETEK PP
1
Top Assembly 7003-422 / 7003-400
A1 7003-703-1 PC Assy. RS232 / GPIB AMETEK PP 1
A1 7003-703-2 PC Assy. RS232 / GPIB AMETEK PP 1
A6
7003
-
702
-
1
PC Assy., Low Volt PSU
AMETEK PP
1
Top Assembly 7003-427 / 7003-422 / 7003-400
A2 7003-408-1 Front Panel Assy., Auxiliary AMETEK PP 1
A3
7003
-
715
-
1
PC Assy., System Interface
AMETEK PP
1
A4 7003-701-1 PC Assy., V / I Sense AMETEK PP 1
A14
7003
-
713
-
1
PC Assy., PWR Interconnect
AMETEK PP
1
A10 7003-714-1 PC Assy., EMI Filter AMETEK PP 1
A7
7003
-
418
-
1
Amplifier Assy., 15kVA
AMETEK PP
1
A8 7003-418-1 Amplifier Assy., 15kVA AMETEK PP 1
A9 7003-418-1 Amplifier Assy., 15kVA AMETEK PP 1
B1 241186 Fan, 3", 24VDC NMB Technology
3110KLO5WB50-P00
1
CB1 270224 Circuit Breaker, 2.5A, 300V AIRPAX
IELH111
-
1
-
61
-
2
-
50
-
D
-
01
-
V
1
K1 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
1
K8 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
1
K2 245236 Relay, 3C, 90A, 24VDC EE Controls
EECLS47.22NTW
1
K6 245236 Relay, 3C, 90A, 24VDC EE Controls
EECLS47.22NTW
1
K7 245236 Relay, 3C, 90A, 24VDC EE Controls
EECLS47.22NTW
1
K9 245236 Relay, 3C, 90A, 24VDC EE Controls
EECLS47.22NTW
1
K3 245237 Relay, 3C, 100A, 24VDC EE Controls 1
