16
Technical data
Operational voltage
Direct voltage 10.8 V – 16.0 V
Current input at 12,5 V
Operation 20 mA – 200 mA
(depends on the brightness of the display)
Standby 2 mA
Temperature
Ambient temperature of -20 °C to +50 °C.
Dimensions / weight
(Model for the retail trade)
Width
138 mm
Height
90 mm
Depth
40 mm
Weight
130 g
The right to effect technical modifications is reserved!
Maintenance instruction
Clean the Check-Panel with a dry, fluff-free cloth.
Procedures in the event of faults
The Check-Panel requires no maintenance. However, if any
faults do occur, please proceed according to the following
table:
Fault Action
The Check-Panel does not
work.
– Check the fuses on the
batteries and replace them
if necessary.
None of the faults described
here seems to apply. But the
device still does not work.
Please contact the
manufacturer.
