Calix GS2028E User Manual

16
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
.
Application Standards
Following is a list of standards that apply to this product:
Standards
FCC Part 15, Sub Part B, class B
UL 62368-1
EN 300 328
CAN ICES-003 Class B
CSA C22.2 No. 62368-1
EN 301 893
ANSI C63.4
IEC 62368-1
EN 301 489-1
FCC Part 15.247
ITU-T K21
EN 301 489-17
FCC Part 15.203
ITU-T K44
EN 55032 Class B
FCC Part 15.207
EN 62368-1
EN 61000-3-2
FCC Part 15. 209
IC: 4009A-U4X
EN 61000-3-3
FCC ID: 2ABLK-U4X
EN 62311
EN 50581
RSS 102
CE / RED, RoHS, WEEE,
Energy
USB 2.0 Type A
RSS 247
IEEE: 802.3, 802.3AB, 302.3U,
802.11p, 802.11Q
EN 50564
FCC Part 15.407
NEC(National Electrical Code)
CISPR 32 Class B
Wi-Fi Alliance Certified 802.11ax
CISPR-22
RCM
8318
Radiated Emissions
 This Class-B digital device complies with radiated emissions requirements as defined in
Canadian ICES-003.
Power Supply
Note: When using the standard power adapter, units will be inoperable after loss of main
power.
 The unit must be powered by a listed power adapter or DC power source marked "LPS"
(Limited Power Source) and rated output between 12 VDC, 2 A minimum, TMA = 40°
C minimum. If additional help is needed on implementing a power supply, please contact
your local Calix service professional.
An external power supply is included with the following rating:
