Calix GS2028E User Manual

32
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
.
Additional Comments
 Once your units LED turns BLUE, you are connected to the upstream WAN modem.
 At start-up, Wi-Fi radios are defaulted to on.
 To configure your BLAST device, connect an Ethernet cable between your PC and the
LAN port of your unit and enter the default IP Address of the device (192.168.1.1) into
your browser.
 Wi-Fi radios can be configured using the default settings:
 SSID: Printed on the product label in the gift box. (CXNKxxxxxxxx)
 Number of radios: 2 (2.4 GHz and 5 GHz)
 Wi-Fi Protocol supported: 802.11a/b/n/g/ac/ax
 Credentials: Login and password printed on the product label in the gift box.
LED States - Power Off & Boot-up
Note: For all LED sequences, the BLAST u4/u4m incorporate a single LED located on the
interface side of the unit.
Power Off and Boot-up
Description
Colors
Indication
OFF
 Power is Off
 The unit has not been turned on
or
 There is no power to the unit
or

Any auxiliary battery has been discharged and can
no longer power the unit.
Off
Booting Up, SW Upgrade in Process
 Unit is in the process of booting up or
services/software is being upgraded

Flashing ever 1 second assuming software can
control the LED
Off & Cyan
Cycles @
1000 msec
 Boot-up Failure

Unit boot-up has failed (assuming software can
control the LED).
Off & Red
Cycles @
800 msec
