Cambridge Audio Edge NQ Manual

EDGE NQ
11
EN ITDE SVFR RUES 中文 日本語
Technical specication
D/A Converter: THD <0.0008%, 20Hz - 20kHz, 24-bit, 1Vrms output
THD Analog sources: <0.0008%, 20Hz – 20kHz, 1Vrms output
Frequency Response: 20Hz-20kHz +/- 0.1dB
S/N ratio (ref 1V output): >103 dB
Crosstalk @ 1kHz: < -100dB
Max preamp output: 6Vrms single ended or 6Vrms + 6Vrms balanced.
USB audio input: USB Audio Class 2.0 supporting up to 32-bit 384kHz PCM, or up to DSD256
USB drive input: 1 x USB 2.0 current limited to 1A, FAT32 / NTFS / HFS / HFS+
Bluetooth: 4.1 (Smart/BLE enabled) A2DP/AVRCP supporting SBC, AAC, Qualcomm® aptX™ and aptX™ HD audio
TOSLINK input: 16/24-bit 32-96kHz
Coax SPDIF input: 16/24-bit 32-192kHz
Wi-Fi: IEEE 802.11 b/g or n (2.4GHz), Encryption WEP, WPA, WPA2
Ethernet: IEEE 802.3, 10 Base-T or 100 Base-T
Max power consumption: 100W
Standby power consumption: <0.5W
Dimensions: 120 x 460 x 405mm (4.7 x 18.1 x 15.9”)
Weight: 10.2kg (22.4lbs)

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
