Cambridge Audio Edge NQ Manual

1 42 3 5
Front panel
1. STANDBY/ON
Switches the unit between Standby mode
(indicated by dim LED) and On (indicated by
bright LED).
AUTO POWER DOWN (APD)
The product will automatically switch to
standby mode after inactivity of 20 minutes.
To enable or disable this function, use the
Cambridge Edge Remote app.
2. HEADPHONES
For suitable headphones – connection will
automatically mute the pre-out.
3. DISPLAY
4. IR SENSOR
5. VOLUME/SOURCE SELECTOR
To change the volume, rotate the front part.
To select a source, rotate the back part.
1. CURRENT SOURCE
2. SOURCE INDICATION
3. ICONS
Firmware update notication, headphones, usb media and network
connection.
Note: Edge NQ will automatically display a notication when it is
connected to a network and new rmware is available. To update the
rmware use either the Edge Remote app or the product webmin page.
Display
2 31

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
