CAMBRIDGE CXA60 - Setup Menu Configuration; Auto Power Down (APD) Settings; Clipping Function Control; USB Mode Selection (CXA80)

5
CXA60/80
Setup menu
Access the Setup menus in Standby mode. Press and hold the Speaker A/B
I\[[VU\U[PS[OL()SPNO[ZÅHZOHS[LYUH[LS`HUK[OLZV\YJLZ((SPNO[\W:LL
ILSV^ZV\YJLI\[[VUZMVYZL[\WJVUÄN\YH[PVU!
Note: Button selected is represented by Blue light.
Auto power down (APD)
(VɈ(VɈ¶+PZHISLZ[OL(7+(\[VWV^LYKV^UM\UJ[PVU
(VU(VɈ¶:L[Z[OL(7+[PTL[VTPU\[LZ
(VɈ(VU¶:L[Z[OL(7+[PTL[VTPU\[LZ
A1 on/A2 on – Sets the APD time to 60 minutes.
Clipping function
A3 on – Clipping function enabled. The volume nudges down if signal clipping
is detected.
(VɈ¶*SPWWPUNM\UJ[PVUPZKPZHISLK
USB mode (CXA80 only)
A4 on – Puts the CXA in USB Class 2 mode.
(VɈ¶7\[Z[OL*?(PU<:)*SHZZTVKL
Notes:
– To save the setup settings and exit the setup menu, press the Speaker A/B
button.
– Pressing the Standby/On button while in the setup menu will exit and not
save the settings.
Control Bus
The Control Bus allows any compatible Cambridge products to synchronise
when powering up the units. See the following diagrams when connecting the
CXA using the provided Control Bus cable.
Another added feature with this Control Bus is the use of the Cambridge
Connect app. You can use the Cambridge Connect app to control the CXA
via the CXN.
Cambridge Connect app (via CXN)
>OLU\ZPUN[OLHWW[V[\YU[OL*?5VUVɈ[OPZ^PSSHSZV[\YU[OL*?(VUVɈ
The app can also be used to control the volume of the CXA. Connect the CXN
control bus out to CXA in. For more information, see the CXN manual.
