ThunderSync3-16 Page 27 of 41
6. Product Specifications
The ThunderSync3-16 is manufactured in the UK
6.1. Input Power Requirements
Input Voltage (V) 100 - 250
Input Current (A) 3.5
Input Connector C14
6.2. Output Power
Output Voltage (V) 5
Output Voltage Tolerance (%) +/-5
Output Current, Max per Port (A) 2.4
Output Power, Max per Port (W) 12
Output Power, Total (W) 230
6.3. Rail value limits
Five volt rail Max (V) 5.58
Five volt rail Min (V) 4.5
6.4. Physical specifications
Upstream connector type Thunderbolt™ 3
Downstream connector type USB 3.2 Type-A
Maximum Downstream Data Speed per Port (Gbps) 5
Ambient Operating Temperature range °C 10-35
Relative, non-condensing, humidity operating range (%) 5 - 95
Dimensions WxDxH (mm) 431 x 262 x 44
