CAMBRIONIX ThunderSync3-16 User Manual

ThunderSync3-16 Page 29 of 41
6.7. Hub Architecture
Below is a diagram of the internal architecture for the ThunderSync3-16.
Fig Description
1 This is the external physical port number
2
This is present if this component is connected to an internal
hub, if it is present the number represents the port number on
the internal hub
Background
colour
Description
An External physical port you can connect a USBdevice to
