6 SPECIFICATION
6. Specification
Output power
1 kHz, THD ≤ 1%, in dual channel operation
typical values @ 230 V / 50 Hz
durationlimitedbyfuse/thermalprotectionforRL≤8Ω
2 × 600 W @ 16 Ω
2 × 1 100 W @ 8 Ω
2 × 1 900 W @ 4Ω
2 × 1 950 W @ 2,7Ω
2 × 1 500 W @ 2Ω
Peak output power
1 kHz, single sine wave in dual channel operation
typical values @ 230 V / 50 Hz, may be subjected to component tolerances
2 × 630 W @ 16Ω
2 × 1 240 W @ 8Ω
2 × 2 250 W @ 4Ω
2 × 2 000 W @ 2,7Ω
2 × 1 500 W @ 2Ω
Mono bridge operation output power
1 kHz, THD ≤1%,inmonobridgeoperation
typical values @ 230 V / 50 Hz
durationlimitedbyfuse/thermalprotectionforRL≤16Ω
1 kHz, single sine wave in mono bridge operation
typical values @ 230 V / 50 Hz, may be subjected to component tolerances
1 × 2 200 W @ 16 Ω
1 × 3 800 W @ 8 Ω
1 × 3 000 W @ 4 Ω
1 × 2 480 W @ 16 Ωpeak
*
1 × 4 500 W @ 8 Ωpeak
*
1 × 3 000 W @ 4 Ωpeak
*
70 / 100 V line operation output power
1 kHz, THD ≤1%
* only possible in mono bridge operation (single channel)
2 × 1 800 W @ 70 V line
1 × 2 500 W
*
@ 100 V line
Circuitry Bipolar, Class H 2 step high efficiency circuit
Signal to noise-ratio
10 Hz – 20 kHz, 8 Ωload
> 102 dB (unweighted)
> 105 dB (A-weighted)
Power consumption @ 230 V
* both channels driven at 250 W output power (approx. of max. THD limited output power
with pink noise to represent typical music signal)
Amplifier standby (power off): 8 W
Idle (Amp powered on): 70 W
4Ω:1 220W
*
2Ω:1 500W
*
Maximum output voltage
in dual channel operation; typical values @ 230 V / 50 Hz
± 142 V peak
Maximum output current
in dual channel operation; typical values, may be subjected to component tolerances
± 39 A peak
