USER MANUAL
i -SERIES
i-SERIES
advancEd amplIfIERS
P.9
MODEL :
OUTP UT PWR P ER C H/IMP:
MADE IN GE RMANY
S ER . NO.:
iD 4
220 V ~ 50 / 60 Hz 11,3 A 1220 W
1900 W / 4 Ohm
xxxxx
2 THE AMPLIFIER
2.1 iD4 – The Front
 Signal-LEDs
 Clip-LEDs
 Character LCD
 Channel buttons
 Item buttons
 Menu buttons
 Rotary encoder with push button
 Removable air filter system
 Cooling air inlet vents
 On/Off switch
2.2 iD4 – The Rear
XLR – line input 1
XLR – line input 2
AES input
Ethernet network input
Cooling air outlet vents
SPEAKON® output 2
SPEAKON® output 1
Rating plate
AC power cable
      

