Camco iD4 - Page 22

USER MANUAL
i -SERIES
i-SERIES
advancEd amplIfIERS
P.22
6 SPECIFICATION
Latency Min. 0,58 ms
Digital inputs AES / EBU, 16 to 24 bit, 44,1, 48, 88,2, or 96 kHz
AC mains
* Approximative mains voltage range where the amplifier can be used.
Amplifier output power performance will decrease with lower mains voltages than the rated 230 V / 220 V / 120 V and slightly
increase with higher mains voltages.
230 V AC, 50 / 60 Hz (for Europe), 190 – 263 V
*
220 V AC, 50 / 60 Hz (for China), 190 – 263 V
*
120 V AC, 50 / 60 Hz (for US), 95 – 134 V
*
Operating temperature +5 °C to +55 °C / +41 °F to +131 °F
Dimensions (W × H × D) 483 × 88,1 × 419 mm / 19 × 3,5 × 16,5 inches (19”, 2U)
Net weight 9,4 kg / 20,7 lbs
Shipping dimensions (W × H × D) 600 × 105 × 527 mm / 23,3 × 4,1 × 20,7 inches
Shipping weight 11 kg / 24,3 lbs
We reserve the right to make technical alterations without prior notice.
