CAME A5000A User Manual

Page 20 - Manual FA01810-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
CAME S.p.A.
Via Martiri della Libertà, 15
31030 Dosson di Casier
Treviso – Italy
Tel. (+39) 0422 4940
Fax (+39) 0422 4941
ELECTRICAL CONNECTIONS
Before working on the control panel, cut o the mains power supply.
Remove the protective cover to access the terminal block.
For space reasons, capacitors for the 110 V versions should be connected to the control panel.
Connecting 2 motors to a ZA3P or ZM3E control panel.
1
234
L2T
L1T
0
24
12
QUADRO COMANDO
FUSIBILI
LINEA 5A
ZA3
CH1
AF
FUSIBILE
CENTRALINA
2A
T.L.
T.C.A.
TR2M.
21 345678910O
N
CH2
U V W X Y E E3
10 11 S 1 2 3 3P 4 5 7 2 C1 CX B1 B2
L1 L2
U
V
W
X
Y
U V W U V W
M1
M2
Reposition the opening stop microswitch assembly because when the gate is open the microswitch assembly is
at the end of the piston and the wire needs to be extended (not supplied).
