CAME BKS08ALS Installation Manual

0
17
24
FR
1
2
3
4
SP
0
10 11 TS 1 L N U V W E1 EX W L1T L2T CT VS VF 24V 0
10 11 TS 1 2 3 3P 4 5 7 CX CY L N U V W E1 EX W L1T L2T CT VS VF 24V 0
CAME
p. 15 - Manual FA01292-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
Flashing light connection output (contact
rated at: 24 V AC - 25 W max).
SIGNALING DEVICES
Gate state warning output (contact
rated for 24 V AC - 3 W max.).
See function
F10.
Additional light connection output (contact
rated at: 230 V - 60 W max).
180 seconds.
Blue
Brown
Charcoal
Black
White
Red
Accessories power
supply output 24 V
AC, max 20 W.

To vary the motor torque, move
the shown faston to one of the four
positions; from 1 (min.) to 4 (max.).
Orange
120 / 230 V AC 50/60 Hz
POWER SUPPLY
Fan

CAME BKS08ALS Specifications

General

Brand	CAME
Model	BKS08ALS
Category	Gate Opener
Language	English
