CAME BX241

10
All the data and information contained herein is considered subject to change at any time and at our discretion
ENGLISH
11
E
L1
L2
+10
-11
1
2
2
3P
M
N
2
C1
2
FC
F
FA
2
C3
F
FC
2
7
6.6 Electrical connections
FC
F
M
FA
N
10
10
11
11
E1
E1
1
1
2
2
3
3
3P
3P
C1
C1
C3
C3
7
7
24V
AC
+
-
L1
L2
M
230V (a.c.) power supply
24V(d.c.) motor
24V output in motion (e.g. fl ashing light 25W)
24V powering accessories max. 40W
Pushbutton stop (N.C.)
Pushbutton partial opening (N.O.)
Contact radio and/or pushbutton for controlled (see dip-switch 2-3)
Contact (N.C.) for «re-aperture during closure»
(24V-3W max.) gate-opened signal lamp
Contact (N.C.) for «partial stop»
Connection limit switch opens
Connection limit switch closes
Antenna connection
N.B. Maintain polarity when connecting photoelectric cells (DIR)
48 


48 # .#



48 28
2
3
Pushbutton open (N.O.)
