p. 6 - Manual FA00000-EN - 02/2018 - © CAME S.p.A. - "Translated original instructions"
KEY
This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
The measurements, unless otherwise stated, are in millimeters.
DESCRIPTION
Operator with control board, movement control and obstruction detecting device plus mechanical stops for sliding
gates of up to 400 kg and 10 m in length.
INTENDED USE
The operator is designed to power sliding gates in residential and apartment block settings.
Do not install of use this device in any way, except as specifi ed in this manual.
LIMITS TO USE
Type BXL04AGS
Maximum gate-leaf length (m) 10
Maximum gate-leaf weight (kg) 400
Pinion module 4
TECHNICAL DATA
Type BXL04AGS
Protection rating (IP) 44
Power supply (V - 50/60 Hz) 230 AC
Input voltage motor (V) 24 DC
Max draw (A) 7
Stand-by consumption (W) 7.4
Stand-by consumption with the RGP1 (W) module 1.2
Maximum power (W) 150
Duty cycle (%) 50
Operating temperature (°C) -20 to +55
Apparatus class I
Weight (Kg) 7.7
