p. 22 - Manual FA01442-EN - 12/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
Safety devices test
Check that the photocells connected to the inputs are operating correctly, after each opening and closing command.
F5 Safety devices test 0 =Deactivated (Default)
1 = CX
2 = CY
4 = CX+CY
Hold-to-run
With the function active, the operator stops moving (opening or closing) when the control device is released.
When the function is active, it excludes all other control devices.
F6 Hold-to-run 0 =Deactivated (Default)
1 = Activated
Command 2-7
Associate a command with the device connected to 2-7.
F7 Command 2-7 0 = Step-by-step (default)
1 = Sequential
2 = Open
3 = Close
Command 2-3P
Associate a command to the connected device on 2-3P.
F8 Command 2-3P 1 = Partial opening
The partial opening time is set from the function [Partial opening time].
2 = Open
Obstacle with motor stopped
With the function active, the gate remains idle if the safety devices detect an obstacle. The function is active when the gate is closed, open or after a complete stop.
F9 Obstacle with motor stopped OFF (Default)
ON
Gate-open warning light
It signals the gate status.
F10 Gate-open warning light 0 = Warning light on (default) - The warning light stays on when the gate is moving or
open.
1 = Warning light flashing - The warning light flashes every half second when the gate
is opening and stays on when the gate is open. The light flashes every second when
the gate is closing, and remains off when the gate is closed.
Encoder
Manage operator slowdowns, obstacle detection and sensitivity.
F11 Encoder OFF
ON (Default)
