3 12/2016 © CAME S.p.A. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME S.p.A. to notify users.
Control board power supply: 230 A.C. 50/60Hz
Motor power supply: 24V D.C.
Max draw: 15A
Power: 180W
Opening time (90°): adjustableGear ratio: 1/709
Max. torque: 470 Nm
Duty Cycle: Intensive use
Protection Rating: IP54
Weight: 14 kg
Operating
temperature
Gearmotor
This product is engineered and manufactured by CAME S.p.A. and complies with current safety regulations.
The gearmotor is composed of two, cast aluminium half shells inside of which rest the gearmotor and endstops – with electro blo-
cking – and an endless screw, epicycloidal gear reduction system.
DESCRIPTION
Intended use
LEGEND OF SYMBOLS
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
INTENDED USE AND RESTRICTIONS
The FERNI 24V operator is specifi cally engineered to automate residential and condominium swing gates, even under intensive
use.
The use of this product for purposes other than those described above and installation executed in a manner other than as instructed
in this technical manual are prohibited.
Restrictions
Technical features
Lengt of gate wings: up to 4 metres. Max. angle of gate wing when open: 90°.
We suggest you always fit an electrolock onto swing gates for a more reliable
closure.
Fitting electrolocks onto reversible operators makes for anti-intrusion
security.
You must install electrolocks onto irreversible operators with gate leaves
exceeding 2.5 m.
Gate leaf width
m
Gate leaf weight
kg
2.00 800
2.50 600
3.00 500
3.50 450
4.00 400
20°C
55°C
