130 min
(1)
(1) (2) (3)
M4 UNI5721
I
p.
7
7 - Manual code:
119U31EN
119 U31EN v.
7
7 -
10/2016
10/2016 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
* See chapt. 4.4 Dimensions
Open the lock cover (1).
Insert the key, push it down and turn it clockwise (2).
Lift the cover, loosen the M4 hex nut and remove the cover from the gearmotor assembly (3).
Hinge
Closing strike plate.
i = 240 mm max.
with 90° opening
Opening angle
ABC
90°
140÷205 0÷50 430
140÷195 75÷100 430
140÷185 125÷150 400
140÷175 175÷200 400
110°
180÷210 0 430
200÷205 50 430
Installing the gearmotor
