Pillar bracket
Extra bracket
Gate bracket
Connect the gearmotors to the panel as shown in the diagram.
ZA3N/ZM3E Control panel
Connecting the 230V a.c. delayed opening
gearmotor
Connecting the 230V a.c. delayed closing gearmotor
Power supply
230V a.c. - 50/60 Hz
