Pag.
2 - Manual code:
319T98EN ver.
2.0 11/2012 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
The ZL80_ZL80C control boards(The ZL80C: featuring incorporated buttons and safety stop) have been specifically designed for
C-BXE24 automation, to drive sectional, sliding and folding doors.
The use of this product for purposes other than as described above and installation executed in a manner other than
as instructed in this technical manual are prohibited.
4 Descrizione
2 Intended use and application
3 Reference Standards
For its quality processes management Came Cancelli Automatici is ISO 9001: certified, and for its environmental management it is
ISO 14001 certified. Came designs and manufactures entirely in Italy.
This product complies with the following standards: see Declaration of Compliance.
Make sure you respect the distances and cable diameters as shown in “cable types and minimal thicknesses” table.
The overall power of the motors must not exceed 450 W.
This product is engineered and manufactured by CAME cancelli automatici s.p.a. and complies with current safety regulations.
The control panel works on 230V a.c. of power, 50/60Hz frequency.
Both command and control devices and accessories are 24V powered. Warning! Accessories must not exceed 36 W overall.
All connections are protected by quick fuses, see table.
The input and output contact functions, the timing settings and users’ management, are set and viewed on the display, which is run
by software.
FUSES
protection: fuse type:
Line 1.6A - F
Electronic board 1A - F
Accessories 1.6A - F
Motors 10A - ABC
TECHNICAL FEATURES
Power supply 230V - 50/60Hz
max. rated power 360W
Power draw when idling 55mA
Max power of 24V accessories 36W
Insulation rating II
Material ABS
Protection rating IP54
operating temperature -20 / +55°C
2.1 Intended use
2.2 Application
1 Legend of symbols
This symbol indicates sections to be read with particular care.
This symbol indicates sections concerning safety.
This symbol indicates notes to communicate to users.
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL INSTALLERS OR QUALIFIED PERSONS”
