CAME ZT6 Installation Manual

11
All the data and information contained herein is considered subject to change at any time and at our discretion.
ENGLISH
( B )
( B )
TRANSMITTER ENCODING
TOP
T434M - T314M
         
 
 
C
Set code only
P1 = CH1
P2 = CH2
P3 = CH3
P4 = CH
4
See instruction sheet inside the
package
TAM
T432 - T434 - T438
See instruction sheet inside the
package
TFM
T132
- T134 - T138
T152 -
T154 - T158
See instruction sheet inside the
package
STANDARD ENCODING PROCEDURE
1. assign a code (also for records)
2. insert jumper code J
3. save it
4. disconnect jumper J
TOP QUARZATI




CAME
Press P1 or P2 in sequence in order to register the
code; at the tenth pulse, a double beep will confi rm
that the code is saved.
TOP
432S
- 434MA -
432NA
