All the data and information contained herein is considered subject to change at any time and at our discretion.
10
ENGLISH
Frequency /
MHz
board Transmitter
FM 26.995 AF130 TFM
FM 30.900 AF150 TFM
AM 26.995 AF26 TOP
AM 30.900 AF30 TOP
AM 433.92 AF43S / AF43SM TAM / TOP
AM 433.92 AF43SR ATOMO
AM 40.685 AF40 TOUCH
A- INSERT AN AF CARD **. B - ENCODE TRANSMITTER/S. C - STORE CODE IN THE BASE CARD.
( A )
( A )
AF BOARD INSERTION
TOP
TAM
(**) For transmitters with 433.92 Supereterendina frequency (TOP and
TAM series), position the jumper as illustrated on the respective AF 43S
card
SCHEDA BASE
SHEDA “AF”
The AF board should ALWAYS be inserted when the power is off because the
motherboard only recognises it when it is powered

 
   
   
ATOMO
AT01 - AT02 - ATO4
see instruction sheet inside the package of the AF43R
CAME
TOP
T432M - T312M
Set the code to dip-switch C and channel to D (P1=CH1 and P2=CH2, default setting)
D
C
P1
P
2
CH1
CH
2
CH
3
CH
4
CH1
CH
2
CH
3
CH
4
5.10
5.10
5.10
Installation of radio-controls
( B )
( B )
TRANSMITTER ENCODING
