CAME ZT6 - Electrical Connections; Power Supply and Motor Terminals; Auxiliary Outputs and Indicators; Control Inputs and Safety Devices

7
ENGLISH
The data and information provided in this manual are to be considered susceptible to change at any time without warning, by CAME cancelli automatici s.p.a.
Power supply: 400V (AC) three-phase (380-COM) and 230V (AC)
three-phase (220-COM)
Connection of antenna
Output 230V (AC.) in motion (e.g. fl ashing lamp - max. 25W)
Cycle or courtesy lamp (230V) (Cycle lamp Dip 16 OFF Dip 17
ON)-(Courtesy light Dip 16 ON Dip 17 OFF) max 60 W.
Contact outlet (N.O.) Contact capacity: 5A at 24V (DC)
Single-phase/three-phase motor 230/400V (AC) max.750 W
End stop connection opens (N.C.)
End stop connection closes (N.C.)
Power supply
accessories 24V (AC)
Output 24V (AC)
in motion
}
Max.20 W
Output for control of 2 coupled motors
Power supply: 230V (AC) single-phase (220-Com)
Stop button (N.C.)
Open button (N.O.)
Button for partial opening (N.O.)
Closing button (N.O.)
Radio contact and/or control button (see dip-switch
2-3 sel. functions) (N.O.)
Contact (N.C.) «Re-closing during opening»*Dip 8 OFF and
Dip 9 OFF) Contact (N.C.) partial stop (Dip 8 OFF Dip 9 ON
Contact (N.C.) of «Re-opening during closure
Warning light (24V-3W max.) “gate closed”
Warning light (24V-3W max.) “gate open”
Electrical connections
2Mot
U-V-W
R-S-T
2-C1
2-CX
2-7
2-4
2-3P
2-3
1-2
6-11
5-11
R-S
E-E1
E-EX
E4-10
10-11
F-FC
F-FA
B1-B2
EN
