EZ-IN

Series Turbine Flowmeter Manual

Figure 6—Positioning of vanes

1. Insert the vanes

so that the arrow on

the blade points in the

direction of flow.

2. Make sure that the blade

with the arrow marking is

positioned in the notch closest

to the bottom of the meter bore.
