Cameron NUFLO EZ-IN Series User Manual

EZ-IN
®
Series Turbine Flowmeter Manual
24
Specications and Parts Lists
Temperature and Pressure Ratings
Flange Classication
CL 150 CL 300 CL 600 CL 900 CL 1500 CL 2500
Design-Operating
Temperature Range
Maximum Working Pressure
psi (mPa)
-20 to l00°F 285 740 1480 2220 3705 6170
( -28.8 to 37.7°C) (1.96) (5.1) (10.2)
(15.3) (25.5) (42.5)
200°F 260 680 1360
2035 3395 5625
(93.3°C) (1.79) (4.7) (9.38)
(14.03) (23.4) (38.8)
400°F 200 635 1265
1900 3170 5280
(204.4°C) (1.38) (4.38) (8.72) (13.1) (21.8) (36.4)
450°F 185 620 1235 1855 3092 5152
(232°C) (1.28) (4.27) (8.5) (12.79) (21.32) (35.52)
